Specific configurations are as follows:
Dimensions: 14900mm long * 3000mm wide * 1800mm high
Load capacity: 80t before extension; 50t after towing extension
Main beam: 500mm high, top plate: 20mm, side plates: 2 x 12mm, bottom plate: 20mm
Loading surface length: 7700mm
Towing extension length: 4500mm
Axles: Xuanrui/factory standard 2-line 4-axle 20t
Trailer tires: Linglong/Chengshan, 265/70R19.5, 16 pcs
Rims: Thickened steel rims, 7.5, 16 pcs
WABCO brand valves
Thickened mechanical suspension
Diesel engine
Weight: 20.5t
Outriggers: 28t
Ton pin: 50# or 90#
Trailer paint: Electrostatic powder coating
Spare tire rack: 1 pc
Tool locker: 1 pc
Electrical system: 12V, handshake connector
